Atlas Bipod V8 Series | BT10 | Picatinny Mount | w/o QD

Without Quick Disconnect

The BT10 V8 Atlas Bipod mounts directly to any 1913 style Picatinny rail via a low profile two screw clamp assembly.

It is comprised of 6061-T6 aluminum that is Mil-Spec Type III hard coat anodized and have heat treated stainless steel components. Available in black only.

Selected for SOCOM MK14 MOD 2. NSN 1005-01-601-000

• Height Range: 4.8 - 9.1" (6.3” at 90°)
• Preloaded Pan: 30 degrees
• Preloaded Cant: 30 degrees
• Position Button 0.36" diameter
• 5 leg positions: 0, 45, 90, 135 & 180 degrees
• Weight: 11.0 ounces approx.
• Footprint: 8–11"
• Designed, Engineered, Machined and Assembled in America
